的主要用途与概况/Brief Introduction：

该线由渐渐式挤出机螺杆洗瓶真空干躁一身机、服食液罐装轧盖机二台手机单机手机游戏主成，包含洁净、干躁消毒和罐装塑封三工作中区，全面可互通生产加工，也可手机单机手机游戏选择。可提交淋水、多普勒彩超波洁净、冲水、冲气、真空干躁消毒、冷去、罐装、理盖、戴盖、轧盖等繁琐流程。The line is made up of two single machine, one straight-line screw bottle washing and drying machine and one oral liquid filling and capping machine. The line is divided into cleaning, drying, sterilization and filling sealing three workspace, all can joint production, also can use single. It can complete water spray, ultrasonic cleaning, water flushing, air flushing, drying sterilization, cooling, filling, cap arranging, capping, sealing, etc.

的特点/Characteristic：

用于高周波波擦拭及水雾间歇性冲刷、远红外持续高温灭菌处理、双头包装与密封等技能。整线连动自己保持。操控简便有利，保证了电气三合一化。Using ultrasonic cleaning and water washing alternately, far-infrared high-temperature sterilization, such as long filling and sealing technology. The automatic control of the whole line linkage. Simple and convenient operation, electromechanical integration is realized.

技术性技术指标/ Technical Parameters：

生产能力technical parameters	80-150瓶/分80-150 bottles/min
适用性尺寸规格 Cutting dimension	5-20ml
电  容  量Amount of electric capacity	65Kw(之中普通运转36Kw)(including normal working 36 kw)
服务器毛重machine net weight	6800Kg
外形尺寸boundary dimension	9650×2360×1900mm（长×宽×高）(length x width x height)
