应用领域与简价/Brief Introduction：

全电脑自行齿轮泵式膏体酱包一键装机都是我集团转变市場需求分析开发建设的新商品。机械采用了SUS304不透钢齿轮泵式计量校准泵履行内包装，且集电脑自行上盖、电脑自行旋盖、汽车电器高压电器为一身，区域经济通用性，征占表面积小，常见软件于药业有限公司、食材、农药杀虫剂、石油化工、美容品等这个行业的液體内包装，遵循GMP想要想要。Automatic plunger paste paste filling machine is my company to meet the market demand, introduction of foreign advanced technology to develop new products. This machine adopts SUS304 stainless steel plunger metering pump filling, cover and set for automatic, automatic screw cap, integration of the mechanical and electrical, economical and practical, cover an area of an area small, widely used in pharmaceutical, food, pesticides, chemical industry, cosmetics and other industries of liquid packaging, full compliance with GMP requirements.

的特点/characteristic：

◆按照柱塞泵式计量检验泵制定灌装线，用于各式各样黏黏度夜体，定位精性高；泵的的结构按照快接式拆装工作平台，更方便清洁工作、杀菌。Adopt plunger type metering pump filling, used various viscosity liquid, high precision; The structure of pump adopts fast disassembly institutions, easy cleaning and disinfection◆液压泵式测量泵活塞式环的板材通过行业内及液状体部分的各种采取硅橡胶制品，四氟丁二烯或一些的板材，特别情况采取陶瓷图片的板材。Plunger metering pump piston ring material according to the industry and different adopt silicon rubber, liquid ingredients tetrafluoroethylene or other material, special occasions with ceramic material◆PLC调节系统化，变频式变速，智能化层面高。PLC control system, frequency control of motor speed, a high degree of automation◆缺瓶不分装，一键计算效果。Lack of bottle filling, automatic counting function◆装量修改便捷，可是次修改全部的量值溯源泵的充填量，也可争对个个量值溯源泵确定微幅修改；进行操作简单便捷，修改便捷。The load adjustment is convenient, can be a filling quantity of all pumps also can be slightly adjusted according to various metering pump; Simple operation, rapid adjustment◆包装生产线针头具有防滴漏问题试验装置，充填时潜泳到瓶底包装生产线，慢变高，严防起泡。Filling needles a drip-proof device, filling into the bottom of the bottle filling, slowly rising and prevent bubbles.◆主机可应用不一样的型号的塑料瓶子，设定简变，可在多日间内进行。The machine is suitable for various specifications of bottles, easy adjustment, it can be finished in a short period of time◆设备按GMP请求开发。The machine designed according to the requirements of GMP

技术工艺因素/technic parameter：

适于小瓶规格尺寸Size of bottles	20-1000ml（通过追求订制）20-1000 - ml (according to your need）
应用水瓶座厚度Apply the bottle diameter	¢20-¢150mm
适于盖子品种Apply the lid specifications	¢20-¢70mm
的生产销量力 production capacity	四头灌装设备：1000-2500瓶/小的时候 Four filling head: 1000-2500 bottles per hour 八头包装：2500-4000瓶/小时候 Eight head filling: 2500-4000 bottles per hour 12头装罐：4000-6000瓶/钟头 12 head filling: 4000-6000 bottles per hour
装量计算误差The load error	±1%
旋盖及格率Screw cover percent of pass	≥99%
电power supply	380V，50HZ
公率power	3.0KW
气动阀门gas sources	0.4-0.75MPA
效率抑制speed control	直流变频变速variable speed
