使用与百科/Brief Introduction：

超声波焊接机是成为内服方式液玻璃板板瓶的新產品，切底消除了不同内服方式液玻璃板板瓶的劣质效用。用此灌封机选用的氟可乐瓶，虽然不想要洗瓶机、烘箱机，更不想要消毒杀菌，应该会直接灌封。此机东莞激光切割管机的理瓶、进瓶、装罐生产线，装罐生产线量不稳，无漏滴，无瓶不装罐生产线。上盖、封膜率可达到100%。此机枝术优秀，重量小、执行不稳、噪音低，工作维修培训、刷洗不方便等优缺点，可以非常符合GMP细则。This machine is a new product instead of oral liquid bottles, thoroughly solved before the adverse effect of oral liquid glass bottle. The used plastic bottles, filling and sealing machine not only don't need to bottle washer, dryer, more don't need disinfection, can be directly potting. The machine is fully automatic unscramble bottle, bottle feeding, filling, filling volume stability, no LouDi, no bottle no filling. Cover and sealing rate can reach 100%. This machine technology is advanced, small volume, stable running, low noise, convenient operation and maintenance, cleaning, etc, in full compliance with GMP standard.注：本规格有低速行驶和高速的两者生产量供您挑选。Note: this model has two kinds of low speed and high-speed production for your choice.

亮点 Characteristic

◆远程服务器选应用于不同易折瓶内服液计量校准包装和粘口。The machine is suitable for all kinds of folding bottles of oral liquid filling and sealing of measurement.◆所以机械零件均用老牌企业。All electrical components adopt famous brand◆该设备工作客观事物便于，无瓶不灌装线，计算*。It has intuitive and convenient operation, no bottle no filling, measuring precision.◆易折PVC瓶灌封机的其主要组成与目的Easy to fold the main structure and principle of plastic bottle filling and sealing machine◆NFGFY型口服方式液易折塑料件瓶灌封机重点理瓶器、理盖器、主传送机系统、导入带孔径送小瓶装制、空罐检漏装制、灌装生产线企业、除去装制、熔接封企业、气动平衡机手指头夹瓶企业、系列伺服直流无刷电机孔径上瓶企业与出瓶企业等分为。Type NFGFY oral liquid is easy to fold the plastic bottle filling and sealing machine main GaiQi bottle opener, and the main transmission system, the synchronous belt clearance to send bottle device, empty bottle leak detection device, filling body, eliminating device, hot melt sealing mechanism, pneumatic mechanical fingers bottle gap on the bottle structure, servo motor and a bottle of institutions, etc.◆器机采用的补血口服液液易折塑瓶、盖不是定整洁区生产的的，可以有药粉材经营证，故瓶身与底盖经信息传递和"去业务外包"后可一直进去灌封间。实现理盖器、理瓶器的系统自动定向分配就业特别整理，剔出单向底盖及瓶身底口朝下的瓶，使定向分配就业后的包材喂料有要求地进去输料单轨中。Machine using oral liquid is easy to fold the plastic bottles, cover a certain production of clean area, should have the medicine packaging material license, so the bottle and the bottom cover after transfer and "outsourcing" can go directly into the potting. By Richard GaiQi, automatic directional arrangement of bottle opener, eliminate reverse bottom cover and the bottom of the bottle mouth bottle at the bottom, after making the orientation of packaging material feeding regularly into orbit. ◆定向招生后服用液易折塑料材质瓶在传输道路里排Directional oral liquid after folding plastic bottles in conveying rail out easily

技巧因素technical parameters：

型号model	NLGFY-40	NLGFY-80
装量使用范围The load range	5-100ML
生产能力production capacity	20-40瓶/分	50-80瓶/分
封膜率Hot sealing intensity	》99%
装量偏差The load error	《1.5%
破损掉镀率damage rate	《1.0%
工作效率power	2KW	3KW
电原Power Supply	380V 50Hz/220V 50Hz
外形尺寸boundary dimension	2700*1100*1900mm	3000*1480*1900mm
质量 Weight	700Kg	800Kg
